HS-5000 2X

HS-5000 2X
Click image to zoom
HS-5000 2X

HS-5000 2X

login to view price
SKU: HS-5000 2X

Type
(Not available)

Short Description

Features of the HS-5000 2X Slit Lamp Microscope
▪ Haag-Streit Style Tower Illumination
▪ Galilean Converging Binocular Optical System
▪ 2-Step Drum Magnification (10x, 16x)
▪ Impressive Field of View
▪ Continuous Slit Height 0.3mm to 14mm
▪ Continuous Slit Width 0mm to 14mm

▪ Slit Angle: 0° to 180° continuously adjustable from vertical to horizontal
▪ Continuous Slit Rotation, Plus Tilt Mechanism
▪ Five Built-in Filters, Including Yellow
▪ Omnidirectional Joystick with Trigger
▪ 12.5x Eyepiece
▪ Durable, Quality Design


HS-5000 2X Slit Lamp Microscope Huvitz - US Ophthalmic

 Design
The HS-5000 2X features a Haag-Streit Style Tower Illumination System that sits above the observation system, allowing the illumination column to be decoupled in the vertical meridian. This allows greater flexibility when minimizing unwanted reflections during gonioscopy and increases the peripheral field of view during indirect ophthalmoscopy.

HS-5000 2X Slit Lamp Microscope Huvitz - US Ophthalmic

 Microscope
HS-5000 2X features a Galilean Converging Binocular optical system that delivers crisp images and a wide field of view. Operators can select from total magnification ratios equivalent to 10x (∅22.3mm) and 16x (∅15.2mm).

HS-5000 2X Slit Lamp Microscope Huvitz - US Ophthalmic

 Magnification Control System
The uniquely designed Huvitz optic system eliminates image distortion at all magnification levels, enabling you to achieve a more precise diagnosis. The unit’s two-position drum-style magnification changer provides easy access to magnification from 10x to 16x with the 12.5x eyepiece

HS-5000 2X Slit Lamp Microscope Huvitz - US Ophthalmic

 Illumination
A 12-volt, 30-watt high luminance halogen lamp provides incredible clarity in this Haag-Streit Style Tower Illumination slit lamp.

HS-5000 2X Slit Lamp Microscope Huvitz - US Ophthalmic

 Five Filters, Including Yellow
Five built-in Illumination Pathway Filters can be effortlessly inserted into the illumination pathway using the selection lever. Options include a heat absorption filter that aids in patient comfort during lengthy exams, a red-free filter that enhances structural contrast, a cobalt blue filter for use in fluorescein assessment, a grey filter, and a yellow filter to absorb blue light and enhance contrast.

HS-5000 2X Slit Lamp Microscope Huvitz - US Ophthalmic

 Integrated Control
The omnidirectional style joystick is simple to control. An integrated trigger button allows for convenient image and video capture. When the slit lamp is connected to imaging devices, images and videos can be stored simultaneously.

HS-5000 2X Slit Lamp Microscope Huvitz - US Ophthalmic

 Ergonomicaly Designed Illumination Control
The illumination lever is conveniently located next to the joystick. The brightness control switch can be set to High or Normal, making diagnostic procedures even easier.

High Quality Standards
From design to production, the Huvitz name is one you can trust.


Durability is Assured
All Huvitz slit lamps are made to be durable, even in extreme conditions. Joints and moving parts undergo tens of thousands of repeated operations to ensure long lifetime use.


Smooth Precision Movement
The easy operation of the joystick and knobs factor into making diagnostic procedures even easier. Every movement with the HS-5000 2X is designed to be smooth and precise.


International Quality Assurance
All Huvitz slit lamps are certified by the international quality assurance system.

Slit Illumination
Slit Length(mm) 0.3~14
Slit Width (mm) 0~14 continuous
Slit Projection 1x
Aperture Diaphragms 0.02 / 0.04 / 0.11 / 0.19 / 0.4 / 0.47in (0.3 / 1 / 3 / 5 / 9 / 12mm)
Filters Cobalt Blue, Red-Free, Gray, Heat absorption and Yellow
Slit Rotation 0°~180°continuous
Patient's Eye / Prism
Angle of Incidence 0°, 5°, 10°, 15°, 20°
Surface Working Distance 3.14in (80mm)
Microscope
Type Galilean Converging Binocular
Magnification 2 Position Rotating Drum
Eyepieces 12.5x
Total Magnifications 10x, 16x
Real Fields of View (mm) 38.5,22.2, 15.2, 10.5, 6.7
Inter-Pupillary Adjustment 2.16in~3.14in (55mm~80mm)
Base
Vertical Movement 1.10in (28mm)
Longitudinal Movement 3.07in (78mm)
Lateral Movement 3.85in (98mm)
Fine Base 0.4in (10mm)
Voltage Frequency 50/60Hz
Power Consumption 70VA
Instrument Voltage 12V DC
Halogen Bulb 12V 30W
Fixation Point Bulb 6V 0.2A
OPTION: PC, Table Designs and details can be changed without prior notice for the purposes of improvement
Click here to see the manual


USO

Manufacturer: USO

Manufacturer SKU: HS-5000 2X

Huvitz HS-5000 2x Slit Lamp Microscope, Haag-Streit style illumination tower, Galilean Converging Binocular Optical System, delivering a wider field of view with crisp clear images. From design to production, the Huvitz name is one you can trust. Now, with the addition of the HS-5000 2X, you can enjoy a quality slit lamp featuring world-class optics at an outstanding price. This Haag-Streit Style Tower Illumination system features a Galilean Converging Binocular Optical System and a two-position, drum-style magnification changer that offers great field of view and a crisp clear image every time. Every movement with the HS-5000 2X is designed to be smooth and precise. Plus, an omnidirectional joystick with trigger button and five built-in filters are among the many “extras” you’ll enjoy when selecting the quality designed slit lamp. The HS-5000 2x is a smart choice for the budget-conscious practice.
