EZ-OPH-2600 Coaxial Ophthalmoscope

Click image to zoom
EZ-OPH-2600 Coaxial Ophthalmoscope
EZ-OPH-2600 Coaxial Ophthalmoscope
EZ-OPH-2600 Coaxial Ophthalmoscope
EZ-OPH-2600 Coaxial Ophthalmoscope
EZ-OPH-2600 Coaxial Ophthalmoscope
EZ-OPH-2600 Coaxial Ophthalmoscope
EZ-OPH-2600 Coaxial Ophthalmoscope

EZ-OPH-2600 Coaxial Ophthalmoscope

login to view price
SKU: EZ-OPH-2600

(Not available)

Short Description



Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer
Coaxial Optics
Coaxial optics directs the axis of the light to coincide with the axis of the vision into the retina thus eliminating possible shadows. This optical system facilitates easy entry into undilated pupils and vitreous disorders through high-precision lamp filament and optical alignment. This enables for more accurate examinations and diagnoses.

18 Unique Aperture and Filter Combinations
This high-end device also contains an extraordinary 18 unique aperture and filter combinations, for greater versatility. Having a diverse amount of filters provides optimum light levels for entering healthy eyes and those with cataracts. This device has essential diagnostic filters including: Cobalt Blue, Cross-linear Polarizing / Red-free.
Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer
Micro-Spot Aperture: allows quick entry into small, undilated pupils.
Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer
Small Aperture: provides excellent view of fundus through an undilated pupil.
Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer
Large Aperture: standard aperture for a dilated pupil and general examination of the eye.
Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer
Fixation Aperture: has graduated cross-hairs for measuring eccentric fixation or locating lesions.
Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer
Slit: used to determine levels of lesions and tumors
Pro Lead Coaxial Ophthalmoscope ez-oph-3600 ezer
Cobalt Blue Aperture: blue filter used with fluorescein dye permits easy viewing of small lesions, abrasions, and foreign objects.
Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer Red-free Filter: excludes red rays from examination field for easy identification of veins, arteries and nerve fibers.

Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer

3.5V Halogen Lamp
The EZ-OPH-2600’s incredible 3.5V Halogen lamp provides light output for true tissue color and consistent, long-lasting illumination. The lamp type of the device is a selected option between Halogen and LED depending on the preference of the operator.

Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer

Opening Selection Dial
Offers six normal openings

Neutral Filter
It offers the ideal amount of HPX ™ halogen light to enter healthy eyes without undesirable reflections.


It can be part of the following kits:


Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer


Kit 1
Included: EZ-OPH-2600, EZ-RET-2600, EZ-HND-2600, EZ-CHG-3600, EZ-OPH/RET-CASE

Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer


Kit 2
Included: EZ-OPH-2600, EZ-RET-2600, EZ-HND-700 (2)

Pro Lead Coaxial Ophthalmoscope ez-oph-2600 ezer


Kit 3
Included: EZ-OPH-2600 (Lamp Type: Halogen), EZ-RET-2600 (Lamp Type: Halogen), EZ-WTC-5200 DC

Kit 4
Included: EZ-OPH-2600 (Lamp Type: LED), EZ-RET-2600 (Lamp Type: LED), EZ-WTC-5200 DC
Optical Specifications
Diopter OD, ±1D, ±2D, ±3D, ±4D, ±5D, ±6D, ±7D, ±8D, ±9D, ±10D, +12D, ±15D, ±20D, -25D, +40D
Aperture Large aperture, small aperture, micro aperture, slit aperture, cobalt blue aperture & fixation aperture.
Filter Red free filter / Polarizing filter
Bulb 3.5 V / 2.7 W
Operation Mode Intermittent, On-time should not exceed 2 mins with Off-time not less than 5 mins.
Electrical Safety Standard Complying with EN60601-1 / EN60601-1-2
Environment Requirements
Operation Environment Temperature
Relative Humidity
Atmospheric Pressure
+10 °C - +35 °C
30% - 75%
700 hPa - 1060 hPa
Shipping Common Conveyance
Storage Temperature
Rel. humidity
Air Pressure
-40 °C - +55 °C
10% - 90%
500 hPa - 1060 hPa
Click here to see the manual


USO

Manufacturer: USO

Manufacturer SKU: EZ-OPH-2600

Any ophthalmology clinic knows the importance of having quality devices, to guarantee a great service to its patient. That is why the use of a good ophthalmoscope allows professionals to evaluate the structures of the eye without dilating. This is what the EZ-OPH-2600 portable device achieves since it combines 28 focusing lenses to achieve an accurate and quality resolution during eye evaluation. The Ezer OPH-2600 makes exams more complete during revisions in non-dilated pupils even if they have cataracts as it includes two filter options to achieve the optimal level of light.
